1.scope of application
rotary kiln belongs to rotary cylinder equipment and is widely used in non-ferrous metallurgical industry (such as alumina roasting, copper oxide reduction, zinc oxide reduction, tin concentrate arsenic removal, ferronickel reduction roasting, tungsten concentrate roasting, ferrochrome pellet pre-reduction, titanium dioxide roasting, kaolin roasting, etc.),ferrous metallurgical industry (such as lean iron ore magnetization roasting, blast furnace ironmaking pellet roasting, pellet direct reduction, etc.) chemical industry (such as lithium carbonate acid roasting, carbon products calcination, etc.), building materials industry, etc.
2.model and specification
model: φ 4×30~φ 6.96×52
cylinder length (m): 30~52
3.product introduction
rotary kiln is composed of cylinder unit, supporting unit, block wheel unit, transmission unit, kiln head and tail sealing unit, kiln head fixed screen, structural cooling bellows and lubrication system. our company is a professional manufacturer of rotary kiln equipment in china. it developed and produced rotary kilns in the 1970s and has produced more than 100 sets so far. among our products, rotary kiln has a maximum diameter of 8.28 meters and a maximum length of 165 meters, which is characterized by low failure rate, low energy consumption and convenient maintenance.
our products adopt professional intelligent centralized lubrication system, which is convenient for centralized control; through professional monitoring equipment, the temperature in the kiln and whether the refractory material is damaged or fallen off can be monitored at any time to avoid accidents; equipped with cooling system and cylinder protection unit, which can effectively prolong the service life of the cylinder; a variety of sealing forms, such as flake laminated seal, labyrinth seal, cylinder compression seal, have been designed and developed, with good sealing effect and long service life; multi-segment gear ring technology is adopted to facilitate transportation and customization of product spare parts.
our company has comprehensive independent design and development capacity, strong production and manufacturing capacity of large equipment and rich equipment installation and operation experience, and can provide professional technical support。
4.experiences
experience in china: mcc north and benxi steel group project (61 sets)
experience overseas: türkiye, myanmar, etc (13 sets)
